Application

Preparation

• Follow all ACI recommendations.
• Remove all contaminants such as dirt, grease, and loose materials.
• Profile concrete substrates to a minimum CSP #4; shot blasting is preferred.

Priming

• Prime withSpecPoxy 1000at approximately 100 sq. ft. per gallon.
• Apply using a notched squeegee, broom, or roller.
• While epoxy is still wet, broadcast coarse dry sand to refusal.
• Allow to dry for a minimum of 12 hours, then remove loose sand before applyingSpecLevel PCT-Gray.

Mixing Instructions

• Small Batches:Mix 7 pints of water per 50 lb. bag for 3 minutes.
• Large Batches:For 34 bags, mix for 45 minutes.
• Pumping:Mix for 3 minutes in the pump’s mixing tank.
• Extended Mix:Add 15 lbs. of 3/8” pea gravel per 50 lb. bag during the last minute of mixing.

Installation

• PourSpecLevel PCT-Grayover the substrate and spread with a long-handled spreader or gauge rake.
• Self-levels in the first 20 minutes at 70°F.
• Accepts foot traffic in 24 hours.
• Use cleated shoes during installation for best results.

50 lb. Bag: Covers approximately 15 sq. ft. at 3/8” thickness.

• Shelf Life:12 months in unopened bags stored in a dry facility.
• Storage:Store in a cool, dry area away from direct sunlight.

• Thickness:Apply from 3/8” up to 1.5”. For thickness up to 5”, add pea gravel.
• High-load Traffic:Floors subject to high-load rubber-wheeled traffic require a minimum of 1/2”.
• Foot Traffic:Accepts foot traffic within 3 to 4 hours depending on job site conditions.

• Set Time at 70°F (ASTM C266):Initial Set 60 min, Final Set 100 min
• Compressive Strength (ASTM C109):1 day: 2500 psi7 days: 4000 psi28 days: 5000 psi
• Bond Strength (ASTM C882 modified):7 days: 1350 psi
• Flexural Strength (ASTM C348):28 days: 1100 psi
• Yield/Density:Yield per bag: 0.45 cu-ft (135 lbs/cu-ft)

Clean tools, pumps, and equipment with water before SpecLevel PCT-Gray hardens.
